Format control file for piping material sum list

/* @(#)PipeSum_csv.frm1.1 04/01/27 */

/* Format control file for piping material sum list */

p PAGE/* name of the page */

40 /* number of lines */

170 /* page width in chars */

0 /* empty lines at the top of the page */

0 /* empty lines at the bottom of the page */

0/* number of empty chars in the right margin */

f Pro /* name of the field */

0 /* output mode */

0 /* normal - bold printing */

0 /* normal - underline printing */

0 /* ignore – print field */

1 /* line position */

1 /* column where printing of the field is to start */

%s;/* output format */

f dat 0 0 0 0 1 40 Date: %s;

f tma 0 0 0 0 1 60 Total weight: %s kg

r LINE0 0 0 1 1 0 0

f O10 0 0 0 1 1 Description;

f O20 0 0 0 1 41 Dimensions;

f O30 0 0 0 1 77 Rating;

f O40 0 0 0 1 88 Material;

f O50 0 0 0 1 119 Standard;

f O60 0 0 0 1 140 Pcs/m

e itm /* name of the element */

1 /* location of the element */

40 /* maximum number of columns */

0 /* normal – bold print */

0 /* reserved for future use */

0 /* printed – not printed */

%s;/* output format */

e dim 41 35 0 0 0 %s;

e rat 77 10 0 0 0 %s;

e mat 88 30 0 0 0 %s;

e std119 20 0 0 0 %s;

e amo140 15 0 0 0 %14s
